The RA201 splitter allows to use just one VHF antenna to simultaneously receive the AM/FM and AIS radio signals: furthermore, the VHF transceiver can also be used.

FEATURES, FUNCTIONS AND SPECIFICATIONS:
It is a compact, economical and safe element, easy to install in any place.
It requires only a 12V power supply with maximum of just 25 mA power consumption.
It is provided with a coaxial input for the antenna and three outputs for VHF, AM/FM radio and AIS.
Thanks to an electronic circuit specifically developed by Glomex and the presence of a built-in preamplifier, the RA201 splitter is able to offer high performance in its three applications, ensuring effective transmission and reception for VHF.
The splitter maximum power for VHF is 100 W, therefore twice as much as most devices on the market.

TECHNICAL SPECIFICATIONS:
BUILT-IN PREAMPLIFIER
IMPEDANCE : 50 ohms
VHF MAX POWER : 100 W
POWER SUPPLY : 12 V
CURRENT DRAW : 25 mA
INPUT :
1 from the VHF antenna
OUPUT :
1 to AM/FM radio
1 to AIS receiver
1 to marine VHF radio

Download hier de user manual.

Art. nr. GLOM RA201
